Pig farm ventilation cone exhaust fan large air volume
Fiberglass Ventilation Fan:
The Fiberglass ventilation fan is patented product by Puhui and the patent number is ZL2016 2 0191632.5.
| Ventilation fan | 18" | 24" | 36" | 50" | 51" |
| Voltage | 380V | 380V | 380V | 380V | 380V |
| Rated Power | 250W | 250W | 550W | 1100W | 1100W |
| Rated Current | 0.76A | 0.76A | 1.4A | 2.8A | 3.12A |
| Weight | 26.5KG | 33.5KG | 54KG | 84.5KG | / |
| Blades Rated Speed | 1400rpm | 1400rpm | 630rpm | 450rpm | 610rpm |
| 0 pa Air Volume | 73983/h | 108003/h | 201003/h | 464003/h | 524403/h |
| 25 pa Air Volume | 67003/h | 98003/h | 169003/h | 413003/h | 463003/h |
| Blades Diameter | 457mm | 609mm | 914mm | 1280mm | 1295mm |
| Blades QTY | 4 | 4 | 3/6 | 6 | 3 |
| Drive Methed | direct-driven | direct-driven | belt-driven | belt-driven | belt-driven |
| Installation Hole Size(W*H) | 560*560 | 720*720 |
1075*1075/3 blades 980*980/6 blades |
1390*1390 | 1420*1460 |
1)50”/36” Fiberglass ventilation fan
Product Feature:
Fiberglass shell as a whole, with smooth surface on both sides, anti-corrosive and rust-free for entire service life, small wind resistance, easy to clean up.
6 stainless steel large fan blades, low speed up to large air volume, high negatve pressure.
Designed in streamline appearance, with low wind resistance and high energy efficency SIEMENS motor, energy saving and high efficiency.
Installation opening dimension:
50”: 1400*1400mm
36”: 1020*1020mm
2)24”/18” Fiberglass ventilation fan
Product Features:
Fiberglass shell as a whole, with smooth surface on both sides, anti-corrosive and rust-free for entire service life, small wind resistance, easy to clean up.
Stainless steel or cast aluminum fan blade, high strength, corrosion resistance, long service life to use.
Direct driving mode, speed adjusting available.
Installation opening dimension:
24”: 785*785mm
After-sale Service
Any questions for requests before,during or after sales,we would like to help you any time and
will find you the best solution in 24 hours.
Warranty:one year for the whole machine Genuine spare partswill be provided with best price.
Over board engineer service is available.
Special Customized Service
We will do all the changes(color,name piate and logo)as you need,and will charge extra fee.
Overseas Engineer Service
We are available to send our engineer for aboard service.Only need you to arrange the
accmmodation,transportation and translator.Extra cost for each will be discussed based
on local price level.
